SiE30-408 Method of Troubleshooting
Troubleshooting 77
In Heating with
Subcooled
Degree Control
In ON / OFF
Judgment for
Heating Hot Start
Subcooled degree (SC) = Tc-Tl
Subcooled degree (SC) = Tc-Tl
Indoor electronic extension
valve closes.
Indoor electronic extension
valve opens.
Liquid refrigerant isstagnant in indoor heat exchanger.
(High pressure rises due to heating overload.)
Refrigerant delivery among indoor
units cannot be balanced.
• Indoor unit liquid pipe thermistor
· When the resistance deviates to smaller value.
(Higher temperature detected)
Tc-Tl decreas
es.
(Subcooling does not work.)
Tc-Tl increases.
(Subcooling works excessively.)
· When the resistance deviates to larger value.
(Lower temperature detected)
Tl ≤ 35 °C is detected.
Hot start cancellation delays. (For 3 minutes or less)
Insufficient capacity for
start-up
• Indoor unit liquid pipe thermistor
· When the resistance deviates to larger value.
(Lower temperature detected)
Condition for canceling hot start
Tl ≥ 35 °C or 3 minutes elapse from thermostat ON.
Tc: Equivalent satura
tion temperature of detected value of outdoor high pressure sensor (Pc)
Tl: Detected temperature of indoor liquid pipe thermistor
(Th2 for unitsusing R22 or R407C, R2T for unitsusing R410A)
