SiE30-408 Recording and Playback of Operation Data
Service Checker Type3 Application Edition 141
Make settings of periodical recording.
Click on the “Period. rcd. Start” button.
— Periodical recording starts —
Check whether or not the recording process is in progress.
Check to be sure “In period. recording” is displayed.
To end recording
Click on the “Period. rcd. end” button.
Terminate the Checker and then disconnect wirings.
Period. rcd. start button
Period. rcd. end button
Display of “In period. recording”
