Recording and Playback of Operation Data SiE30-408
140 Service Checker Type3 Application Edition
Make settings of periodical recording.
Setting of recording intervals
— Set the recording intervals to 60 seconds unless otherwise specified by Quality Control
Dept., or else.
Be sure to check the free data space.
After the completion of all settings, click on the “Setting completed” button.
Used to make setting of recording intervals.
Used to check to be sure the free dataspace.
Click thisbutton after the
completion of all settings.
