Motherboard Manual
34
FRENCH
SPEC
UC
Socket AM2+ / AM3
Processeurs AMD Athlon 64 / Athlon 64 FX
/ Althlon 64 X2 / S empron / Phenom /
Phenom II
(Watt maximu m : 95W )
L'architecture AMD 64 permet le calcul 32 et 64 bits
Prend en charge Hyper Transport 3.0 et PowerNow
Bus frontal
Prend en charge Hyper Transport 3.0
jusqu'à une bande passante de 5.2 GT/s
Chipset GeForce 8200
Super E/S
ITE 8718
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à f aib le co mpte de b roches
Initiatives de contrôle environnementales,
Moniteur d e mat ér iel
Fonction "Gardien intelligent" de l'ITE
Mémoire
principale
Fentes DDR2 DIMM x 2
Capacité mémo ire max imale de 8 Go
Chaque DIMM prend en charge des DDR2
de 256Mo/512Mo/1Go/2Go /4Go
Modu le d e mémo ire DDR2 à mode à doub le voie
Prend en charge la DDR2 533 / 667 / 800
Prend en charge la DDR2 1066 (by AM2+ / AM3 CPU)
Les DIMM à registres et DIMM avec code correcteurs
d'erreurs ne sont pas prises en charge
Graphiques Integré dans la chipset GeForce 8200
Mémoire vidéo partagée maximale de 512 Mo
Prise en charge DX10 / HDC P / PureVideo
IDE Contrôleur IDE intégré
Mode principale de Bus Ultra DMA 33 / 66 / 100 / 133
Prend en charge le mode PIO 0~4,
SATA
Contrôleur Serial ATA
int égr é
Taux de transfert jusqu'à 3 Go/s.
Conforme à la spécif icat ion SATA Vers ion 2.0
LAN Realtek RTL 8111DL
10 / 100 / 1000 Mb/s négociation automatique
Half / Full duplex capability
Prise en
charge
audio HD
ALC662
Sortie audio à 5.1 vo ies
Prise en charge de l'audio haut e définition
Fente PCI Express Gen2 x16 x1
Fentes
Fente PCI x2
Connecteur de disquette x1
Chaque connector prend en charge 2 lecteurs de
disquettes
Connecteur IDE x1
Chaque connecteur prend en charg e 2 périp hériques
IDE
Connecteur
embarqué
Connecteur SATA x4
Chaque connecteur prend en charg e 1 périp hérique
SATA
