Especificación
CPU
Conector AM2+ / AM3
Procesadores AMD Athlon 64 / Athlon 64
FX / Athlon 64 X2 / Sempron / Phenom /
Phenom II
(Vatio máximo: 95W)
La arquitectura AMD 64 permite el procesado de 32 y
64 bits
Soporta las tecnologías Hyper Transport 3.0 y
PowerNow
FSB
Admite HyperTransport 3.0 con un ancho
de banda de hasta 5.2 GT/s
Conjunto
de chips
GeForce 8200
Súper E/S
ITE 8718
Le ofrece las funcionalidades heredadas
de uso más común Súper E/S.
Interfaz de cuenta Low Pin
In ic iat ivas de control d e entorno,
Monitor hardware
Función "Guardia inteligente" de ITE
Memoria
principal
Ranuras DIMM DDR2 x 2
Capacidad máxima de memoria de 8GB
Cada DIMM admite DDR de 256MB/
512MB/1GB/2GB/4GB
Módulo de memoria DDR2 de canal Doble
Admite DDR2 de 533 / 667 / 800
Admite DDR2 de 1066 (by AM2+ / AM3 CPU)
No admite DIMM registrados o DIMM compatibles con
ECC
Gráficos
Integrados en el conjunto de chips
GeForce 8200
Memoria máxima de vídeo compartida de 512 MB
Admite DX10 / HDCP / PureV ideo
IDE Controlador IDE integrado
Modo bus maestro Ultra DMA 33 / 66 / 100 / 133
Soporte los Modos PIO 0~4,
SATA Controlador ATA Serie Integrado
Tasas de transferencia de hasta 3 Gb/s.
Compat ib le con la versión SATA 2.0.
Red Local Realtek RTL 8111DL
Negociación de 10 / 100 / 1000 Mb/s
Funciones Half / Full dúplex
Soporte de
sonido HD
ALC662
Salida de sonido de 5.1 canales
Soporte de sonido Alta Definición
Ranura PCI Express Gen2 x16 X1
Ranuras
Ranura PCI X2
Conector disco flexible X1 Cada conector soporta 2 unidades de disco flexible Conectores
en placa
Conector IDE X1 Cada conector soporta 2 dispositivos IDE
