Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS1
VG A1
DVI1
USB1
RJ45USB1
AUDIO1
JKB_PW R1
ATXPW R2
JUSBV1
ATXPWR1
CD_IN1
LAN
Codec
FDD1
PANEL1
SYS_FAN1
F_COM1F_PRINT1F_AUDIO1
Super I/O
PCI2
PCI1
PEX16_1
F_USB1 F_USB2
JUSBV2
BIOS
JCMOS1
IDE 1
GeForce
8200
SATA1
SATA2
SATA3
SATA4
DIMMA1
DIMMB1
Socket AM2+
CPU_FAN1
BAT1
Note: represents the 1■
st
pin.
