GF8200 M2G+
35
SPEC
Connecteur du panneau avant x1 Prend en charge les équipements du panneau avant
Connecteur Audio du panneau avant x1 Prend en charge la fonction audio du panneau avant
Connecteur d'entrée CD x1 Prend en charge la fonct ion d'entrée aud io de CD
Embase de ventilateur UC x1
Alimentation électrique du ventilateur UC (avec
fonction de ventilateur intelligent)
Embase de ventilateur système x1 Alimentation électrique du ventilateur système
Embase d'effacement CMOS x1
Connecteur USB x2
Chaque connecteur prend en charge 2 ports USB de
panneau avant
Connecteur d'aliment ation x1
(24 broches)
Connecteur d'aliment ation x1
(4 broches)
Connecteur de Port d'imprimante x1
Chaque connector prend en charge 1 Port
d'imprimante
Connecteur de Port série x1
E/S du
panneau
arrière
Clavier PS/2 x1
Souris PS/2 x1
Port VGA x1
Port LAN x1
Port USB x4
Fiche audio x3
Port DVI x1
Dimension
s de la
cart e
190 mm (l) X 244 mm (H)
Fonctionnal
ités
spéciales
Prise en charge RAID 0 / 1 / 5 / 0+1
Pr ise en ch arg e Hybr id SLI (by nV ID IA
driver)
Support SE
Windows XP / Vista 32 / Vista 64
Biostar se réserve le droit d'ajouter ou de supprimer le
support de SE avec ou sans préavis.
