GF8200 M2G+
43
SPEC
Złącze panela przedniego x1 Obsługa elementów panela przedniego
Przednie złącze audio x1 Obsługa funkcji audio na panelu przednim
Złącze wejścia CD x1 Obsługa funkcji wejścia aud io CD
Złącze główkowe wentylatora procesora
x1
Zasilanie wentylatora procesora (z funkcją Smart Fan)
Złącze głó wkowe wentylatora
systemowego x1
Zasilanie wentylatora systemowego
Złącze głó wkowe kasowania CMOS x1
Złącze USB x2
Każde złącze obsługuje 2 porty USB na panelu
przednim
Złącze zasilania (24 pinowe) x1
Złącze zasilania (4 pino we) x1
Złącze Port drukarki x1 Każde złącze obs ługuje 1 Port drukarki
Złącze Port szeregowy x1
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS /2 x1
Port VGA x1
Port LAN x1
Port USB x4
Gniazdo audio x3
Port DVI x1
Wymiary
płyty
190 mm (S) X 244 mm (W)
Funkcje
specjalne
Obsługa RAID 0 / 1 / 5 / 0+1
Obsługa Hybrid SL I (b y nV ID IA dr iver)
Obsluga
systemu
operacyjne
go
Windows XP / Vista 32 / Vista 64
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsługi dowo ln ego systemu
operacyjnego bez powiado mienia.
