Motherboard Manual
48
JAPANESE
仕様
CPU
Socket AM2+ / AM3
AMD Athlon 64 / Athlon 64 FX / Althlon 64
X2 / Sempron / Phenom / Phenom II プロ
セッサ
(最高のワット: 95W)
AMD 64アーキテクチャでは、32ビットと64ビット計算が可
能です
ハイパートランスポート3.0とクールアンドクワイアットを
サポートします
FSB
5.2 GT/sのバンド幅までハイパートランスポ
ート3.0をサポートします
チップセッ
ト
GeForce 8200
メインメモ
リ
DDR2 DIMMスロット x 2
最大メモリ容量8GB
各DIMMは 256MB/512MB/1GB/2GB/4GB
DDR2をサポート
デュアル チャンネルモードDDR2メモリモジュール
DDR2 533 / 667 / 800 をサポート
DDR2 1066 をサポート (by AM2+ / AM3 CPU)
登録済みDIMMとECC DIMMはサポートされません
Super I/O
ITE 8718
もっとも一般に使用されるレガシーSuper I/O
機能を採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ITEの「スマートガーディアン」機能
グラフィッ
クス
GeForce 8200チップセットに統合
最大の共有ビデオメモリは512MBです
DX10 / HDCP / PureV ideo のサポート
IDE 統合IDEコントローラ
Ultra DMA 33 / 66 / 100 / 133バスマスタモード
PIO Mode 0~4のサポート、
SATA 統合シリアルATA コントローラ
最高3Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠。
LAN Realtek RTL 8111DL
10 / 100 / 1000 Mb/秒のオートネゴシエーション
半/全二重機能
HDオーディ
オのサポー
ト
ALC662
5.1チャンネルオーディオアウト
ハイデフィニションオーディオのサポート
PCI Express Gen2 x16スロット x1
スロット
PCIスロット x2
フロッピーコネクタ x1 各コネクタは2つのフロッピードライブをサポートします オンボード
コネクタ
IDEコネクタ x1 各コネクタは2つのIDE デバイスをサポートします
