Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+ / AM3
AMD Athlon 64 / Athlon 64 FX
/
Athlon 64 x2
/ Sempron / Pheno m / Phenom II processors
(Maximum Watt: 95W)
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and PowerNow
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset GeForce 8200
Super I/O
ITE 8718
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control in it iatives
H/W Monitor
ITE's "S mart Guardian" funct ion
Main
Memory
DDR2 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+ / AM3 CPU)
Registered DIMM and ECC D IMM is not supported
Graphics Integrated in GeForce 8200 Chipset
Max Shared V id eo Memory is 512 MB
DX10 / HDCP / PureV ideo support
IDE Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 specificat ion co mp liant
LAN Realtek RTL 8111DL
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound ALC662
5.1 channels audio out
High Definition Audio
PCI Express Gen2 x16 Slot x1 Supports PCI-E Gen2 x16 expansion cards
Slots
PCI Slot x2 Supports PCI expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x4 Each connector supports 1 SATA devices
On Board
Connectors
Front Panel Connector x1 Supports front panel facilities
