Motherboard Manual
36
ITALIAN
SPECIFICA
CPU
Socket AM2+ / AM3
Processori AMD Athlon 64 / Athlon 64 FX
/ A lthlo n 64 X2 / S empron / Pheno m /
Phenom II
(Watt massimo: 95W)
L’architettura AMD 64 abilita la co mputazione 32
e 64 bit
Supporto di Hyper Transport 3.0 e PowerNow
FSB
Supporto di HyperTransport 3.0 fino a
5.2 GT/s di larghezza di banda
Chipset GeForce 8200
Super I/O
ITE 8718
Fornisce le funzionalità legacy Super
I/O usate più comunemente.
Interfaccia LPC (Low Pin Count)
Funzioni di controllo dell’ambiente:
Monitoraggio hardware
Funzione "Smart Guardian" di ITE
Memoria
principale
Alloggi DIMM DDR2 x 2
Capacità massima della memoria 8GB
Ciascun DIMM supporta DDR2
256MB/512MB/1GB/2GB/4GB
Modulo di memoria DDR2 a canale doppio
Supporto di DDR2 533 / 667 / 800
Supporto di DDR2 1066 (by AM2+ / AM3 CPU)
DIMM registrati e DIMM ECC non sono supportati
Grafica Integrata nel Chipset GeForce 8200
La memoria video condivisa massima è di 512 MB
Supporto DX10 / HDCP / PureVideo
IDE Controller IDE integrato
Modalità Bus Master Ultra DMA 33 / 66 / 100 /
133
Supporto modalità PIO Mode 0-4
SATA Controller Serial ATA integrato
Velocità di trasferimento dei dati fino a 3 Gb/s.
Compatibile s pecifiche SATA Versione 2.0.
LAN Realtek RTL 8111DL
Negoziazione automatica 10 / 100 / 1000 Mb/s
Capacità Half / Full Duplex
Supporto
audio HD
ALC662
Uscita audio 5.1 canali
Supporto audio High-Definition (HD)
Alloggio PCI Express Gen2 x16 x1
Alloggi
Alloggio PC I x2
Connettore floppy x1 Ciascun connettore supporta 2 unità Floppy Connettori
su scheda
Connettore IDE x1 Ciascun connettore supporta 2 unità IDE
