Motherboard Manual
42
POLISH
SPEC
Procesor
Socket AM2+ / AM3
AMD Athlon 64 / Athlon 64 FX / Althlon 64
X2 / Sempron / Phenom / Phenom II
Procesory
(Maksymalny Watt: 95W)
Architektura AMD 64 umożliwia przetwarzanie 32 i 64
bitowe
Obsługa Hyper Transport 3.0 oraz PowerNow
FSB
Obsługa HyperTransport 3.0 o szerokości
pasma do 5.2 GT/s
Chipset GeForce 8200
Pamięć
główna
Gniazda DDR2 DIMM x 2
Maks. wielkość pamięci 8GB
Każde gniazdo DIMM obsługuje moduły
256MB/512MB/1GB/2GB/4GB DDR2
Modu ł pamięci DDR2 z trybem podwójnego kanału
Obsługa DDR2 533 / 667 / 800
Obsługa DDR2 1066 (by AM2+ / AM3 CPU)
Brak obsługi Registered DIMM oraz ECC DIMM
Super I/O
ITE 8718
Zapewnia najbardziej powszechne
funkcje Super I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Mon itor H/W
Funkcja ITE "Smart Guardian"
Grafika Zintegrowana w chipsecie GeForce 8200
Maks. wielkość współdz ielonej pamięci video wynosi
512 MB
Obsługa DX10 / HDCP / PureV ideo
IDE Zintegrowany kontroler IDE
Ultra DMA 33 / 66 / 100 / 133 Tryb Bus Master
obsługa PIO tryb 0~4,
SATA Zintegrowany kontroler Serial ATA
Transfer danych do 3 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0.
LAN Realtek RTL 8111DL
10 / 100 / 1000 Mb/s z automatyczną negocjacją szybkości
Działanie w tryb ie połowicznego / pełnego dupleksu
Obsługa
audio HD
ALC662
5.1 kanałowe wyjście audio
Obsługa High-Def inition Aud io
Gniazdo PCI Express Gen2 x16 x1
Gniazda
Gniazdo PCI x2
Złącze napędu dyskietek x1 Każde złącze obs ługuje 2 napędy dyskietek
Złącze IDE x1 Każde złącze obs ługuje 2 urządzenia IDE
Złącza
wbudowan
e
Złącze SATA x4 Każde złącze obs ługuje 1 urządzenie SATA
