GF8200 M2G+
39
Especificación
Conector SATA X4 Cada conector soporta 1 dispositivos SATA
Conector de p anel f rontal X1 Soporta instalac iones en el p anel frontal
Conector de sonido frontal X1 Soporta funciones de sonido en el panel frontal
Conector de entrada de CD X1 Soporta función de entrada de sonido de CD
Cabecera de ventilador de CPU X1 Fuente de alimentación de ventilador de CPU (con
función Smart Fan)
Cabecera de ventilador de sistema X1 Fuente de alimentación de ventilador de sistema
Cabecera de borrado de CMOS X1
Conector USB X2 Cada conector soporta 2 puertos USB frontales
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(4 patillas)
Conector Puerto de impresora X1 Cada conector soporta 1 Puerto de impresora
Conector Puerto serie X1
Panel
trasero de
E/S
Tec lad o PS /2 X 1
Ratón PS/2 X1
Puerto VGA X1
Puerto de red local X1
Puerto USB X4
Conector de sonido X3
Puerto DV I X1
Ta maño d e
la placa
190 mm. (A) X 244 Mm. (H)
Funciones
especiales
Admite RAID 0 / 1 / 5 / 0+1
Admite Hybr id SL I (by nV ID IA driver)
Soporte de
sistema
operativo
Windows XP / Vista 32 / Vista 64
Biostar se reserva el derecho de añadir o retirar el
soporte de cualquier SO con o sin aviso previo.
