GeForce 6100-M9

2.2.2 DDR Installation Notice

For AMD K8 939 CPU launched before Rev. E, please follow the table

below to install your DDR memory module, or the system may not

boot up or may not function properly. (Please refer to Table 1 for CPU

Revision)

“SS” represents Single Side DDR memory module.

“DS” represents Double Side DDR memory module.

Star sign “*” represents leave the DIMM socket empty.

DIMMA1 SS/DS

SS/DS SS/DS

DIMMA2

SS/DS SS/DS SS/DS

DIMMB1

* * *

SS/DS

DIMMB2

* * *

SS/DS

2.2.3 Know your CPU version

AMD Athlon 64 Processor Ordering Part Number Example

ADA 3200 A E P 5 AP

Table 1: AMD Athlon 64 Processor Part Definition Options

Part Definition Revision Part Definition Revision

AP Rev C0 BN Rev E4

AR Rev CG BP Rev E3

AS Rev CG BO Rev E3

AW Rev CG BY Rev E6

AX Rev CG BW Rev E6

AZ Rev CG

BI Rev D0

Part Definiti on: AP = Rev C0 (see Table 1)
