Biostar GeForce 6100-M9 Версия 1.x [3/62] Chapter 1 introduction

GeForce 6100-M9

CHAPTER 1: INTRODUCTION

1.1 MOTHERBOARD FEATURES

CPU

Supports Socket 939.

Supports AMD Athlon 64 FX/ Athlon 64/ Athlon 64 X2 processor.

AMD 64 architecture enables simultaneous 32 and 64 bit

computing.

Supports HyperTransport Technology up to 2000MT/s.

Supports AMD Cool’n’Quiet Technology.

Chipset

North Bridge: nVIDIA GeForce6100.

South Bridge: nVIDIA nForce 410.

Dimensions

Micro ATX Form Factor: 24.5cm (L) x 24.45cm (W)

Operating System Supporting

Supports Windows 2000 and Windows XP.

Note: Does not support Windows 98SE and Windows ME.

Slot

Two PCI bus master slots.

One PCI-E x1 slot.

One PCI-E x16 slot.

Super I/O

Chip: ITE IT8712F.

Low Pin Count Interface.

Provides the most commonly used legacy Super I/O

functionality.

Environment Control initiatives,

 H/W Monitor

 Fan Speed Controller

 ITE's "Smart Guardian" function
