GeForce 6100-M9

PCI1~PCI2: Peripheral Component Interconnect Slots

This motherboard is equipped with 2 standard PCI slots. PCI stands

for Peripheral Component Interconnect, and it is a bus standard for

expansion cards. This PCI slot is designated as 32 bits.

PCI2

PCI1

PCI-EX16: PCI-Express x16 Slot

- PCI-Express 1.0a compliant.

- Maximum bandwidth is up to 4GB/s per direction.

PCI-EX1_1: PCI-Express x1 Slot

- PCI-Express 1.0a compliant.

- Maximum bandwidth is up to 250MB/s per direction.

PCI-EX16

PCI-EX1_1
