NF4-A9A / NF4 Ultra-A9A
7
Main Menu Selections
This table shows the selections that you can make on the Main Menu.
Item Options Description
Date mm : dd : yy Set the system date.
Note that the ‘Day’
automatically
changes when you set
the date.
Time hh : mm : ss Set the system
internal clock.
IDE Primary
Master
Options are in
its sub menu.
Press <Enter> to
enter the sub menu of
detailed options
IDE Primary
Slave
Options are in
its sub menu.
Press <Enter> to
enter the sub menu of
detailed options.
IDE Secondary
Master
Options are in
its sub menu.
Press <Enter> to
enter the sub menu of
detailed options.
IDE Secondary
Slave
Options are in
its sub menu.
Press <Enter> to
enter the sub menu of
detailed options.
Drive A
Drive B
360K, 5.25 in
1.2M, 5.25 in
720K, 3.5 in
1.44M, 3.5 in
2.88M, 3.5 in
None
Select the type of
floppy disk drive
installed in your
system.
Video EGA/VGA
CGA 40
CGA 80
MONO
Select the default
video device.
