NF4-A9A / NF4 Ultra-A9A

Step 3: Look for the white triangle on socket, and the gold triangle on CPU should

point forwards this white triangle. The CPU will fit only in the correct

orientation.

Step 4: Hold the CPU down firmly, and then close the lever toward direct B to

complete the installation.

Step 5: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power

cable to the JCFAN1. This completes the installation.
