c. With a user-friendly Status Animation, it can represent 3

overclock percentage stages:

Man walking→overclock percentage from 100% ~ 110 %

Panther running→overclock percentage from 110% ~ 120%

Car racing→overclock percentage from 120% ~ above

3. Voltage Panel

Click the Voltage button in Main Panel, the button will be

highlighted and the Voltage Panel will slide out to up as the

following figure.

In this panel, you can decide to increase CPU core voltage and

Memory voltage or not. The default setting is “No”. If you want to

get the best performance of overclocking, we recommend you click

the option “Yes”.
