12 | Chapter 2: Hardware installaon

PANEL: Front Panel Header

This 16-pin header includes Power-on, Reset, HDD LED, Power LED, and speaker connecon.

Pin Assignment Funcon Pin Assignment Funcon

1 +5V

Speaker Connector

9 N/A

N/A

2 N/A 10 N/A

3 N/A 11 N/A N/A

4 Speaker 12 Power LED (+)

Power LED5 HDD LED (+)

Hard drive LED

13 Power LED (+)

6 HDD LED (-) 14 Power LED (-)

7 Ground

Reset buon

15 Power buon

Power-on buon

8 Reset control 16 Ground

TPM1: Trusted Plaorm Module Header

This header allows you to store cryptographic keys that protect informaon.

Pin Assignment Pin Assignment

1 F_LAD0 2 +3V

3 F_LAD1 4 +3V

5 F_LAD2 6 C_PCICLK_TPM

7 F_LAD3 8 GND

9 F_FRAME# 10 NC

11 F_SERIRQ 12 S_PCIRST#_TBD

13 F_CLKRUN 14 +3VSB

SATA1/ 2: Serial ATA 6.0 Gb/s Connectors

These connectors connect to SATA hard disk drives via SATA cables.

Pin Assignment

1 Ground

2 TX+

3 TX-

4 Ground

5 RX-

6 RX+

7 Ground
