26 | APPENDIX I: Specicaons in Other Languages
Spanish
Especicaciones
Compabilidad con el
procesador
A68N-2100E: AMD® E1-2150 (Dual core 1.05 GHz, 9W)
A68N-2100K: AMD® E1-6010 (Dual core 1.35 GHz, 10W)
A68N-2100X: AMD® PRO A4-3350B (Quad Core 1.2 GHz, 10W)
A68N-5600E: AMD® PRO A4-3350B (Quad Core 2.0 GHz, soporta máx. Hasta 2.4 GHz, 15W)
Memoria
A68N-2100E:
Soporta DDR3 & DDR3L 800/1066/1333 monocanal
A68N-2100K:
Soporta DDR3 & DDR3L 800/1066/1333 (1.25V) monocanal
A68N-2100X:
Soporta DDR3 & DDR3L 800/1066/1333 (1.25V)/ 1600 (1.35V) monocanal
A68N-5600E:
Soporta DDR3 800/1066/1333/1600 monocanal
Soporta DDR3L 800/1066/1333 monocanal
2x DDR3 y DDR3L DIMM Ranura de memoria Soporta hasta 16 GB Memoria
Cada DIMM soporta un modulo non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 y DDR3L
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Conector 2x SATA III (6Gb/s) : Soporta AHCI
LAN
Realtek RTL 8111H
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio
ALC887
Canales Audio de Alta Denición 7.1
USB
Ranura 2x USB 3.1(Gen1) (2 en las entrada/salidas posteriores)
Ranura 6x USB 2.0 (2 en las entradas/salidas posteriores y 4 por los distribuidores internos)
Ranuras de Exnción Ranura 1x PCIe 2.0 x16 (x4)
Panel trasero de E/S
Ratón 1x PS/2
Teclado 1x PS/2
Ranura 1x VGA
Ranura 1x HDMI
Ranura 1x LAN
Ranura 2x USB 3.1(Gen1)
Ranura 2x USB 2.0
Socket audio 3x
Conectores en placa
Conector 2x SATA III 6Gb’s
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Conector con 4 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x1
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor Ranura Serie x1
Distribuidor Ranura Impresora x1
Conector Externo S/PDIF x1
Distribuidor TPM x1
Factor de Forma Factor de Forma Mini-ITX, 170 mm x 170 mm
Soporte OS
Windows 7/ 10
Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
