Biostar A68N-2100E Версия 6.X [4/51] 3 specifications
![Biostar A68N-5600E Версия 6.X [4/51] 3 specifications](/views2/1712355/page4/bg4.png)
4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
A68N-2100E: AMD® E1-2150 (Dual core 1.05 GHz, 9W)
A68N-2100K: AMD® E1-6010 (Dual core 1.35 GHz, 10W)
A68N-2100X: AMD® PRO A4-3350B (Quad core 1.2 GHz, 10W)
A68N-5600E: AMD® PRO A4-3350B (Quad core 2.0 GHz, Max Supports up 2.4 GHz, 15W)
Memory
A68N-2100E:
Supports Single Channel DDR3 & DDR3L 800/ 1066/ 1333
A68N-2100K:
Supports Single Channel DDR3 & DDR3L 800/ 1066/ 1333 (1.25V)
A68N-2100X:
Supports Single Channel DDR3 & DDR3L 800/ 1066/ 1333 (1.25V)/ 1600 (1.35V)
A68N-5600E:
Supports Single Channel DDR3 800/ 1066/ 1333/ 1600
Supports Single Channel DDR3L 800/ 1066/ 1333
2 x DDR3 & DDR3L DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 & DDR3L module
* Please refer to www.biostar.com.tw for Memory support list.
Storage 2x SATA III Connector (6Gb/s) : Supports AHCI
LAN
Realtek RTL 8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio
USB
2x USB 3.1(Gen1) port (2 on rear I/Os)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots 1x PCIe 2.0 x16 Slot (x4)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x VGA Port
1x HDMI Port
1x LAN port
2x USB 3.1(Gen1) Port
2x USB 2.0 Port
3x Audio Jack
Internal I/Os
2x SATA III 6.0Gb/s Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x COM Port Header
1x Printer Port Header
1x S/PDIF out Connector
1x TPM Header
Form Factor Mini-ITX Form Factor, 170 mm x 170 mm
OS Support
Windows 7 / 10
Biostar reserves the right to add or remove support for any OS with or without noce.
