22 | Chapter 4: Useful help

CPU Overheated

If the system shutdown automacally aer power on system for seconds, that means the CPU

protecon funcon has been acvated.

When the CPU is over heated, the motherboard will shutdown automacally to avoid a

damage of the CPU, and the system may not power on again.

In this case, please double check:

1. The CPU cooler surface is placed evenly with the CPU surface.

2. CPU fan is rotated normally.

3. CPU fan speed is fullling with the CPU speed.

Aer conrmed, please follow steps below to relief the CPU protecon funcon.

1. Remove the power cord from power supply for seconds.

2. Wait for seconds.

3. Plug in the power cord and boot up the system.

Or you can:

1. Clear the CMOS data. (See “Close CMOS Header: JCMOS1” secon)

2. Wait for seconds.

3. Power on the system again.
