3.7.2 Date & Time
You can setup the time setting of ICA-350, make it synchronized with PC or remote NTP server.
Also, you may select the correct time zone of your country.
Server Date
& Time
Displays the date and time of the device
PC Time Displays the date and time of the connected PC
Manual setting: Click this option to set time and date manually
Synchronize
with NTP:
Click this option if you want to synchronize the
device’s date and time with those of time server called
NTP server (Network Time Protocol)
Adjust
Synchronize
with PC:
Click this option to enable time synchronization with
PC time
NTP Server Name Type the host name or IP address or domain name of the NTP server.
NTP Sync. Interval Select an interval between 1 and 23 hours at which you want to adjust
the device’s time referring to NTP server
Time Zone Set the time difference from Greenwich Mean Time in the area where the
device is installed.
Daylight Saving Check this item to enable daylight saving adjustment.
Daylight Saving
Start Time
Sets up the date and time of daylight saving start time.
49
