Planet CAM-IVP52V [2/2] Package contents
![Planet CAM-IVP52V [2/2] Package contents](/views2/1071411/page2/bg2.png)
Please read before using
1. Please do not directly touch the sensor element. If neces-
sary, use a soft cloth moistened with alcohol to wipe off
any dust.
2. Please be extra careful not to shake the camera.
3. Please avoid places where there is direct sunlight.
4. When the camera is not in use, keep the lens or the lens
cap attached to protect the sensor.
5. Don’t attempt to service this unit yourself unless you are
authorized to do so. This may exposure you to dangerous
voltage or other hazards. Refer all servicing to qualied
personnel only.
6. Please don’t use the camera under the following abomi
-
nable environments. Temperature is lower than -10
degrees Centigrade, or is higher than +50 degrees Centi-
grade.
Package Contents
• 1 x CAM-IVP52V
• 1 x Quick Installation Guide
• 1 x Waterproof Connector
• 1 x Wrench
• 4 x Screw
Product Specication
General
Image pick-up device 1/3” SONY Super HAD (Hi-Res.) CCD
Effective Pixels
NT: 768(H) x 494(V)
PA: 752(H) x 582(V)
Horizontal Resolution 520 TVL
Lens
3.7~12 mm, F1.6~3.0
Vari-Focal with DC drive Auto Iris lens
Min. Illuminator 0.3 Lux / F2.0; 0 Lux (IR on)
Auto Electronic
Shutter
NT: 1/60~1/100000 sec
PA: 1/50~1/110000 sec
S/N Ratio More than 48 dB
Gamma Characteristic 0.45
White Balance Automatically (2400~9600°K)
Auto Gain Control High / Low
Flickless Mode On / Off (NT: 1/100, PA: 1/120)
Back Light Comp. On / Off
Synchronous System Internal
Video Output Composite 1.0 Vp-p, 75 ohm
IR LED 24 pieces
IR Wavelength 850 nm
IR Distance 25 meters
Vandal Resistant 10 pounds
Water Resistant IP-66
Environment
Power Requirement
DC 12V
IR on: 400mA max. / IR off: 200mA max.
Dimensions 145x110mm(ΦxH)
Weight 1.01 kg
Operating Temperature -10 ~ 50 Degree C
– 1 – – 2 –
