Specifications SiUS34-801A_b
16 VRVIII R-410A Heat Pump 60Hz
Heat Pump 60Hz <RXYQ-PTJU> 230V
Notes: 1 Indoor temp. : 80°FDB or 67°FWB / outdoor temp. : 95°FDB / Equivalent piping length : 25 ft (7.5 m), level difference: 0.
2 Indoor temp. : 70°FDB / outdoor temp. : 47°FDB or 43°FWB / Equivalent piping length : 25 ft (7.5 m), level difference: 0.
3 BHFP22P100U is necessary for the connection.
Concerning about the piping connection for each outdoor unit to the main line as shown above, use REFNET.
Model Name (Combination Unit) RXYQ216PTJU RXYQ240PTJU
Model Name (Independent Unit)
RXYQ96PTJU
RXYQ120PTJU
RXYQ120PTJU
RXYQ120PTJU
Power Supply 3 Phase 60Hz 208V-230V 3 Phase 60Hz 208V-230V
1 Cooling Capacity Btu / h 216,000 240,000
2 Heating Capacity Btu / h 243,000 270,000
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) in
66-1/8 × 36-5/8 × 30-1/8 +
66-1/8 × 36-5/8 × 30-1/8
(1680 x 930 x 765 +
(1680 x 930 x 765 mm)
66-1/8 × 36-5/8 × 30-1/8 +
66-1/8 × 36-5/8 × 30-1/8
(1680 x 930 x 765 +
(1680 x 930 x 765 mm)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m
3
/h (10.53+13.34) × 2 (10.53+13.34) × 2
Number of Revolutions r.p.m (2900, 6300) × 2 (2900, 6300) × 2
Motor Output×Number
of Units
kW (2.2+4.5) × 1 + (3.5+4.5) × 1 (3.5+4.5) × 2
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW (0.75) × 1 + (0.75) × 1 (0.75) × 1 + (0.75) × 1
Air Flow Rate cfm 6,530+7,060 7,060+7,060
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe 3in
φ5/8” (15.8 mm) C1220T
(Brazing Connection)
φ5/8” (15.8 mm) C1220T
(Brazing Connection)
High Pressure Equalizer
Pipe
in
φ3/4” (19.1mm) C1220T
(Brazing Connection)
φ3/4” (19.1mm) C1220T
(Brazing Connection)
Gas Pipe 3in
φ1-1/8” (28.6 mm) C1220T
(Brazing Connection)
φ1-3/8” (34.9 mm) C1220T
(Brazing Connection)
Low Pressure Equalizer
Pipe
in
φ3/4” (19.1 mm) C1220T
(Brazing Connection)
φ3/4” (19.1 mm) C1220T
(Brazing Connection)
Mass Lbs (kg) 560 + 560 (254 + 254 kg) 560 + 560 (254 + 254 kg)
Safety Devices
High Pressure Switch,
Fan Driver Overload Protector,
Overcurrent Relay,
Inverter Overload Protector
High Pressure Switch,
Fan Driver Overload Protector,
Overcurrent Relay,
Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 7~100 6~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge Lbs 19.8+20.1 20.1+20.1
Control Electronic Expansion Valve Electronic Expansion Valve
Standard Accessories
Installation Manual,
Operation Manual,
Connection Pipes, Clamps
Installation Manual,
Operation Manual,
Connection Pipes, Clamps
Drawing No. 4D060128A 4D060129A
