SiUS34-801A_b List of Electrical and Functional Parts
Appendix 513
3.1.4 REMQ96PYDN~120PYDN
Item Name Symbol
Model
REMQ96PYDN REMQ120PYDN
Compressor
Inverter
Type
M1C
JT1GCVDKYR@SA
OC protection
device
14.7A
STD 1
Type
M2C
JT170G-KYE@T
OC protection
device
15.0A
Fan motor
OC protection
device
M1F 3.0A
Electronic expansion valve (Main) Y1E Fully closed : 0pls Fully open : 480pls
Electronic expansion valve (Refrigerant charge) Y2E Fully closed : 0pls Fully open : 480pls
Electronic expansion valve (Subcool) Y3E Fully closed : 0pls Fully open : 480pls
Pressure
protection
High pressure
switch
For M1C S1PH OFF : 580 psi ON : 435±21.75psi
For M2C S2PH OFF : 580 psi ON : 435±21.75psi
Low pressure sensor SENPL OFF : 10.15psi
Temperature
protection
Discharge gas temperature
protection
(Discharge pipe thermistor)
R3T OFF :275°F
Inverter fin temperature
protection
(Radiator fin thermistor)
R1T OFF : 199.4°F
Others Fuse
For main PC
board
F1U Time-lag 3.15A AC 250V / 250V AC 10A Class B
F2U Time-lag 3.15A AC 250V / 250V AC 10A Class B
For Noise filter
PC board
F1U 250V AC 5A Class B
+0
−17.40
+0
−17.40
