f. Filter:
One optional filter can be installed in the IC-703.
Narrow filters help reject interference from adjacent
signals and obtain good selectivity.
Wide filters provide improved audio for SSB opera-
tion when no interfering signals are present.
Narrow filters for AM/FM modes are standard.
FILTER PRESETTING:
After you install a filter (see p. 87 for installation), you
must specify the installed filter in initial set mode (item
“22 OPT. FIL” ; see p. 79).
FILTER ON/OFF:
q Select M3.
•Push [DISPLAY] once or twice to select M.
• Push [MENU] one or more times to select M3.
w Push [(F-1)FIL] momentarily to select the narrow
filter; push for 1 sec. to select the wide filter.
•ã appears when the narrow filter is selected; ç ap-
pears when the wide filter is selected.
NOTE:
When selecting the narrow filter (or wide fil-
ter), the graphic passband is changed (see dia-
gram below).
CH
VFO A
P
O
S1
5
5379
20 40
10
60dB
USB
BLANK
M3 FIL NB MET
N W
[(F-1)]
[MENU] [DISPLAY]
Either these
appears when selected
Normal
operation
wide is
selected
narrow is
selected
We hope these pointers have been helpful. Now you
are ready for the “Ready to call CQ?”.
Quick Reference
