![Icom IC-703 [88/112] Command table continued](/views2/1074390/page88/bg58.png)
73
11
CONTROL COMMAND
Command table (continued)
DD
Band stacking register
To send or read the desired band stacking register’s con-
tents, combined code of the frequency band and register
codes as follows are used.
For example, when sending/reading the contents in the
21 MHz band, the code “0701” is used.
• Frequency band code
• Register code
DD
Codes for memory keyer contents
To send or read the desired memory keyer contents, the
channel and character codes as follows are used.
• Channel code
• Character’s code
DD
Codes for memory name contents
To send or read the desired memory name settings, the
character codes, instructed codes for memory keyer con-
tents as above, and follows are additionally used.
• Character’s code— Alphabetical characters
• Character’s code— Symbols
Command Sub command Description
1A 0314 Send/read RTTY marker fre-
quency (0=1275 Hz, 1=1615 Hz,
2=2125 Hz)
0315 Send/read RTTY shift width
(0=170 Hz, 1=200 Hz, 2=425 Hz)
0316 Send/read RTTY keying polarity
(0=Normal, 1=Reverse)
0317 Send/read noise blanker level
(0=min. to 255=max.)
0318 Send/read key type (0=Normal,
1=Reverse, 2=Bug, 3=OFF,
4=Mic. [UP]/[DN])
0319 Send/read CW keyer dot/dash
ratio (28=1:1:2.8 to 45=1:1:4.5)
0320 Send/read CW keyer repeat time
(01=1 sec. to 60=60 sec.)
0321 Send/read CW keyer transmission
indication (0=Normal, 1=First 3-
character, 2= First 3-character+
contact number)
0322 Send/read contact number style
(0=Normal, 1=190→ANO,
2=190→ANT, 3=90→NO,
4=90→NT)
0323 Send/read count up trigger chan-
nel (1=MK1, 2=MK2, 3=MK3)
0324
Send/read present number (1–999)
04 Send/read DATA mode (0=OFF,
1=ON)
1B 00 Set/read repeater tone frequency
01 Set/read TSQL tone frequency
1C 00 Set/read the transceiver’s condi-
tion (0=Rx; 1=Tx)
01 Set/read antenna tuner condition
(0=OFF, 1=ON, 2=Start tuning or
while tuning)
Character ASCII code Character ASCII code
a–z 61–7A — —
Code Freq. band Frequency range (unit: MHz)
01 1.8 1.800000–1.999999
02 3.5 3.400000–4.099999
03 7 6.900000–7.499999
04 10 9.900000–10.499999
05 14 13.900000–14.499999
06 18 17.900000–18.499999
07 21 20.900000–21.499999
08 24 24.400000–25.099999
09 28 28.000000–29.999999
10 50 50.000000–54.000000
11 GENE Other than above
Character ASCII code
Description
0–9 30–39 Numerals
A–Z 41–5A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
, 2C Symbol
. 2E Symbol
^ 5E e.g., to send
BT
, enter ^4254
✱ 2A Inserts contact number (can be
used for 1 channel only)
Code Channel number
01 MK1
02 MK2
03 MK3
Character ASCII code Character ASCII code
!21#23
$24%25
&26¥5C
?3F ” 22
’27`60
+2B–2D
:3A;3B
=3D<3C
>3E ( 28
)29[5B
]5D{7B
}7D|7C
_5F
–
7E
Code Registered number
01 1
