PANEL DESCRIPTION
$6 LCD FUNCTION DISPLAY (See p.10 for details.)
Shows the operating frequency, function switch
menus, spectrum screen, memory channel screen,
set mode settings, etc.
$7 MEMORY UP/DOWN SWITCHES [
YY
]/[
ZZ
] (p. 50)
➥Select the memory channel number for the se-
lected readout.
•Memory channels can be selected both in VFO and
memory modes.
➥Select the desired memory channel directly after
pushing [F-INP] and a memory channel number.
$8 MEMORY WRITE SWITCH [MW] (p. 52)
Stores the selected readout frequency and operat-
ing mode into the displayed memory channel when
pushed for 2 sec.
•This function is available both in VFO and memory
modes.
$9 MEMORY CLEAR SWITCH [M-CL] (p. 54)
Clears the selected readout memory channel con-
tents when pushed for 2 sec. in memory mode.
•The channel becomes a blank channel.
•This switch does not function in VFO mode.
%0 QUICK TUNING SWITCH [TS] (p. 25)
➥Turns the quick tuning step ON and OFF.
•While the quick tuning indicator is displayed, the fre-
quency can be changed in programmed kHz steps.
•0.1, 1, 5, 9, 10, 12.5, 20 and 25 kHz quick tuning
steps are available.
➥While the quick tuning step is OFF, turns the 1 Hz
step ON and OFF when pushed for 2 sec.
•1 Hz indications appear in both readouts and the fre-
quency can be changed in 1 Hz steps.
➥While the quick tuning step is ON, enters the
quick tuning step set mode when pushed for 2
sec.
%1 TRANSMIT FREQUENCY CHECK SWITCH
[XFC]
Monitors the transmit frequency when pushed and
held when the split frequency function is ON.
•While pushing this switch, the transmit frequency can be
changed with the tuning dial, keypad, memo pad or the
[Y]/[Z] switches.
•When the split lock function is turned ON, pushing [XFC]
cancels the dial lock function. (p. 69)
ANT
1
METER
Po
BWBW
2.4k2.4k
SFTSFT
0
FIL2FIL2
qw:pp
TXTX
CWCW
qr≥qpp≥pp
21.076.5021.076.50
VFOVFO
USBUSB
1
Quick tuning indicator
NB NR
BAL NR
COMP KEY SPEED BK-IN DELAY
LOCKTX
RX
TWIN PBT
CW PITCH
F-1 F-2 F-3 F-4 F-5
SPEECH LOCK
RIT/ TX
TXRIT CLEAR
SPLIT
MP-W MP-R
DUAL
WATCH
VFO/
MEMO
MAIN/
SUB
CHANGE
1.8
1
3.5
2
7
3
10
4
14
5
18
6
21
7
24
8
28
9
GENE
•
50
0
F-INP
ENT
Y
Z
MW
M-CL
TS
XFC
EIVER
i756PRO
PBT CLR NOTCH
NOTCH
SSB
CW/RTTY
AM/FM FILTER EXIT
$7 $8 $9 %0 %1
$6
■ Front panel (continued)
