Icom IC-756PRO [79/84] Internal views
![Icom IC-756PRO [79/84] Internal views](/views2/1074404/page79/bg4f.png)
12
77
INTERNAL VIEWS
PA fuse (FGB 5 A)
PA unit
FILTER unit
Internal antenna
tuner
•Top view
RF unit
PLL unit
Space for optional
voice synthesizer
(UT-102)
MAIN unit
Clock backup battery
•Bottom view
