Icom IC-756PRO [82/84] Transmitter
![Icom IC-756PRO [82/84] Transmitter](/views2/1074404/page82/bg52.png)
•General
•Frequency coverage :
Receive 00.030–60.000 MHz*
1,
*
2
Transmit 01.800–01.999*
2
03.500–03.999*
2
07.000–07.300*
2
10.100–10.150*
2
14.000–14.350*
2
18.068–18.168*
2
21.000–21.450*
2
24.890–24.990*
2
28.000–29.700*
2
50.000–54.000*
2
*
1
Some frequency bands are not guaranteed.
*
2
Depending on version
•Mode : USB, LSB, CW, RTTY, AM,
FM
•Number of memory : 101
(99 regular, 2 scan edges)
channels
•Antenna connector : SO-239×2 and phono
(RCA; 50 Ω)
•Temperature range : –10˚C to +50˚C;
+14˚F to +122˚F
•Frequency stability : Less than ±0.5 ppm 1 min.
after power on.
(–10 to 50˚C;
+14 to +122˚F)
•Frequency resolution : 1 Hz
•Power supply : 13.8 V DC ±15%
•Power consumption :
Transmit Max. power 23 A
Receive Standby 3.0 A (typ.)
Max. audio 3.5 A (typ.)
•Dimensions : 340(W)×111(H)×285(D) mm
(projections not included) 18
3
⁄8(W)×4
3
⁄8(H)×11
7
⁄32(D) in
•Weight (approx.) : 9.6 kg; 21 lb 1 oz
•ACC 1 connector : 8-pin DIN connector
•ACC 2 connector : 7-pin DIN connector
•CI-V connector : 2-conductor 3.5 (d) mm (
1
⁄8˝)
•Display : 5-inch (diagonal) TFT color
LCD
•Transmitter
•Output power (continuously adjustable):
SSB/CW/RTTY/FM 5–100 W
AM 5–40 W
•Modulation system :
SSB PSN modulation
AM Low power modulation
FM Phase modulation
•Spurious emission : 50 dB (HF bands)
60 dB (50 MHz band)
•Carrier suppression : 40 dB
•Unwanted sideband : 55 dB
suppression
•∂TX variable range : ±9.999 kHz
•Microphone connector : 8-pin connector (600 Ω)
•ELEC-KEY connector :
3-conductor 6.35(d) mm
(
1
⁄4")
•KEY connector :
3-conductor 6.35(d) mm
(
1
⁄4")
•SEND connector : Phono (RCA)
•ALC connector : Phono (RCA)
•Receiver
•Receive system : Triple conversion
superheterodyne system
•Intermediate frequencies:
1st 64.455 MHz
2nd 455 kHz
3rd 36 kHz
•Sensitivity (typical) :
SSB, CW, RTTY 0.16 µV
(1.80–29.99 MHz)*
1
(10 dB S/N) 0.13 µV
(50.0–54.0 MHz)
*
2
AM (10 dB S/N)
13 µV (0.5–1.799 MHz)
2 µV
(1.80–29.99 MHz)*
1
1 µV
(50.0–54.0 MHz)
FM (12 dB SINAD) 0.5 µV
(28.0–29.99 MHz)*
1
0.32 µV
(50.0–54.0 MHz)*
2
*
1
Pre-amp 1 is ON, *
2
Pre-amp 2 is ON
•Squelch sensitivity (Pre-amp: OFF):
SSB, CW, RTTY Less than 5.6 µV
FM Less than 1 µV
•Selectivity :
SSB, RTTY More than 2.4 kHz/–6 dB
(BW: 2.4 kHz) Less than 2.8 kHz/–60 dB
CW (BW: 500 Hz) More than 500 Hz/–6 dB
Less than 700 Hz/–60 dB
AM (BW: 6 kHz) More than 6.0 Hz/–6 dB
Less than 15.0 Hz/–60 dB
FM (BW: 15 kHz) More than 12.0 Hz/–6 dB
Less than 20.0 Hz/–60 dB
•Spurious and image : More than 70 dB
rejection ratio (except IF through on 50 MHz
band)
•AF output power : More than 2.0 W at 10%
(at 13.8 V DC) distortion with an 8 Ω load
•RIT variable range : ±9.999 kHz
•PHONES connector : 3-conductor 6.35 (d) mm
(
1
⁄4˝)
•External SP connector: 2-conductor 3.5 (d) mm
(
1
⁄8˝)/8Ω
•Antenna tuner
•Matching impedance range:
HF bands 16.7 to 150 Ω unbalanced
(Less than VSWR 3:1)
50 MHz band 20 to 125 Ω unbalanced
(Less than VSWR 2.5:1)
•Minimum operating : 8 W
input power
•Tuning accuracy : VSWR 1.5:1 or less
•Insertion loss : Less than 1.0 dB
(after tuning)
14
80
SPECIFICATIONS
All stated specifications are typical and subject to change without notice or obligation.
