RECEIVE AND TRANSMIT
■ Digital voice recorder (continued)
•Sending a message for transmit
q Push [EXIT] one or more times to close a multi-
function screen, if necessary.
w Select a phone mode by pushing [SSB] or
[AM/FM].
e Push [(F-2)VOICE] to call up the voice recorder
screen.
r Push [(F-1)PLAY] to select the voice memory
screen.
•If the receive voice memory channel (R1–R4) appears,
push [(F-5)T/R] to select transmit voice memory chan-
nel.
t Push the desired memory channel, [(F-1)T1]–
[(F-4)T4], momentarily to transmit the contents.
y Push the selected memory channel, [(F-1)T1]–
[(F-4)T4], again to stop, if desired.
u Push [EXIT] twice to exit voice memory screen.
•Transmit monitor function
The monitor function can be automatically turned ON
while transmitting a voice memory message.
q Call up the voice recorder screen as described
above.
w Push [(F-5)SET] to select the voice memory set
mode screen.
e Rotate the tuning dial to turn the monitor function
ON and OFF.
•Push [(F-3)DEF] to select the default condition.
r Push [EXIT] to return to the voice recorder screen.
•Transmit level setting
q Call up the voice recorder screen as described at
left.
w Push [(F-3)TX LEV.] to select the voice memory
transmit level set mode screen.
e Push the desired memory channel, [(F-1)T1]–
[(F-4)T4], momentarily to transmit the contents.
r Rotate the tuning dial to adjust the transmit voice
level.
•Push [(F-5)DEF] to select the default condition.
t Push [EXIT] to return to the voice recorder screen.
