10
2
PANEL DESCRIPTION
@0 FREQUENCY SKIP SWITCH [5 SKIP]
➥ Push for 1 sec. to turn the frequency skip func-
tion ON and OFF in VFO mode. (p. 47)
•“P SKIP” appears when the frequency skip function
is in use.
➥ Push for 1 sec. to set the memory channel as the fol-
lowing skip channel in memory mode in order. (p. 48)
• Skip channel — “SKIP” appears.
• Frequency skip channel — “P SKIP” appears.
• Non-skip channel — no skip indicator appears.
➥ Push for 1 sec. to program a paused frequency as a
skip frequency while scanning. (p. 48)
➥ Inputs digit ‘5’ for frequency input, memory channel se-
lection, etc.
➥ While pushing [PTT], this key sends the DTMF code “5”.
@1 MEMORY NAME SWITCH [6 M.N]
➥ Push for 1 sec. to turn the memory name indi-
cation ON and OFF. (p. 39)
•Frequency appears for nameless memory chan-
nels.
➥ Inputs digit ‘6’ for frequency input, memory channel se-
lection, etc.
➥ While pushing [PTT], this key sends the DTMF code “6”.
@2 TONE SCAN SWITCH [7 T.SCAN]
➥ Push for 1 sec. to start a tone scan. (p. 73)
➥ Inputs digit ‘7’ for frequency input, memory
channel selection, etc.
➥ While pushing [PTT], this key sends the DTMF code “7”.
@3 SET MODE SWITCH [8 SET]
➥ Push for 1 sec. to enter the set mode. Push to
select the displayed set mode item after se-
lecting with [DIAL] while in the set mode.
(p. 55)
➥ Inputs digit ‘8’ for frequency input, memory channel se-
lection, etc.
➥ While pushing [PTT], this key sends the DTMF code “8”.
@4 TUNING STEP SWITCH [9 TS]
➥ Push for 1 sec. to select the tuning step.
(p. 18)
➥ Inputs digit ‘9’ for frequency input, memory
channel selection, etc.
➥ While pushing [PTT], this key sends the DTMF code “9”.
@5 RIT/ATTENUATOR SWITCH [0 RIT]
➥ Push for 1 sec. to enter the RIT/attenuator set
mode. Push to select the item after selecting
with [DIAL]. (p. 27)
• RIT function is available for 630.000 MHz and above.
• Attenuator for 629.995 MHz or less only.
➥ Inputs digit ‘0’ for frequency input, memory channel se-
lection, etc.
➥ While pushing [PTT], this key sends the DTMF code “0”.
0
RIT
9
TS
8
SET
7
T.SCAN
6
M.N
5
SKIP
ww
PANEL DESCRIPTION
IC-T90A_IM.qxd 02.6.6 08:44 AM Page 13 (1,1)
