Icom IC-T90A [95/100] Options
![Icom IC-T90A [95/100] Options](/views2/1074446/page95/bg5f.png)
Flexible boom micro-
phone and rotating ear-
piece with a spring
earhook.
SP-13 EARPHONE
Provides clear receive
audio in noisy environ-
ments.
LC-152A CARRYING
CASE
Helps protect the transceiver from scratches, etc.
CP-19
CIGARETTE LIGHTER CABLE WITH NOISE FILTER
Used for operation and charging a battery pack connected to
the transceiver via a DC power source. (11.5–16 V DC)
CS-T90A CLONING SOFTWARE + OPC-478 CLONING
CABLE
Allows you to transfer data from memories, etc. and quickly
and easily edit and store data via a PC for Microsoft
®
Windows
®
95/98 and ME. 1 RS-232C (COM) port is required.
OPC-474 CLONING CABLE
Used for handheld-to-handheld cloning.
CP-19
90
14
OPTIONS
Microsoft
®
and Windows
®
are registered trademarks of Microsoft Cor-
poration in the U.S.A. and other countries.
VOX
PTT
HS-94
VS-1
!!44
OPTIONS
IC-T90A_IM.qxd 02.6.6 08:45 AM Page 93 (1,1)
