QUICK REFERENCE
■ VFO/MEMORY MODE selection
VFO mode : Push [VFO].
MEMORY mode : Push [MR].
■ Changing frequency band
Push [BAND].
■ Frequency setting
q Select VFO mode.
w Rotate [DIAL], or enter the desired
frequency from the keypad.
[e.g. 1] 445.600 MHz
[4], [4], [5], [•], [6], [0], [0]
[e.g. 2] 0.684 MHz
[0], [•], [6], [8], [4]
■ Changing receiving mode
Push [MODE].
■ Adjusting audio output level
Push [∫]/[√] (continuously changes
while holding).
■ Adjusting squelch level
While pushing [SQL] rotate [DIAL].
■ MEMORY channel selection
q Select MEMORY mode.
w Rotate [DIAL], or use keypad.
■ MEMORY channel programming
[e.g.] Program 445.600 MHz into MR
CH 2
q Select VFO mode.
w Rotate [DIAL], or use keypad to
set 445.600 MHz.
e Push and hold [MR S.MW] for
1 sec. to indicate memory channels.
r Rotate [DIAL] to select MR CH 2.
t Push and hold [MR S.MW] for
1 sec. (VFO mode is selected after
programming.)
■ MEMORY channel clearing
q Select the desired memory channel.
w Push and hold [MR S.MW] for 1 sec.
w Push [CALL/TV] several times to
select “CLR”.
e Push and hold [MR S.MW] for
1 sec. to clear the information.
■ Scanning in VFO mode
q Select VFO mode.
w While pushing and holding [MODE
SCAN], rotate [DIAL] to select
scan edge from full (ALL), band
(BAND) and program (PROG
0–24) scans.
e Release [MODE SCAN] to start the
scan.
r Push [VFO] to stop the scan.
■ Scanning in MEMORY mode
q Select MEMORY mode.
w For the memory bank scan, push
[MR] to select memory bank mode
and push [BAND] to select the de-
sired memory bank.
e While pushing and holding [MODE
SCAN], rotate [DIAL] to select
scan mode from memory (ALL)
and bank (BANK) scans.
r Release [MODE SCAN] to start the
scan.
t Push [VFO] to stop the scan.
