OTHER FUNCTIONS
NOTE: While receiving a signal (on a frequency other than
the weather alert ON frequency), the receiving signal or
audio will be interrupted momentarily every 5 sec.
(approx.)
in the case that the alert function is turned ON. This symp-
tom is caused by the WX alert function. To cancel these
symptoms, set the weather alert item OFF in set mode.
oo
OTHER FUNCTIONS
