BASIC OPERATION 4 4 1 SELECTING A CHANNEL 1 Rotate PWR VOL clockwise to turn ON power Channel 16 is displayed 2 Select your desired mode Dial mode push DIAL Weather channel mode push WX 4 2 INSTANT ACCESS TO CHANNEL 16 Channel 16 is an emergency distress and call channel Access Channel 16 instantly in any of the following ways Push CH 16 2 Turn power OFF and then turn it ON again 3 When you have pushed DIAL select U S A or interna tional channels If you have pushed WX proceed to Hang the microphone on the microphone hook step 4 To switch between U S A and International channels push and hold HI LO and then push CH 16 4 Rotate the channel selector to set your desired channel 7
