BASIC OPERATION 4 1 Select the operating channel See Section 4 1 for details 2 Push HI LO to select transmit power Either HI or LO is displayed Transmission is restricted on some channels 3 Push and hold the PTT switch to transmit The red TX indicator lights 4 Speak into the microphone at your normal voice level Do not hold the microphone close to your mouth or speak with a loud voice This may distort the signal 5 Release the PTT switch to receive TRANSMITTER RESTRICTIONS CHANNEL NUMBER U S A CHANNELS INTERNATIONAL CHANNELS 13 Momentary high power No restriction 15 Receive only Low power only 17 Low power only Low power only 67 Momentary high power No restriction WEATHER CHANNELS Receive only MOMENTARY HIGH POWER On these channels transmissions using high power are momentarily possible To transmit using high power push and hold HI LO and PTT 9
