INSTALLATION 2 2 CONNECTION 3 ANTENNA Use a 12 V DC power source and be sure of the following The single most important item that influences the perfor mance of any communication system is the antenna Ask your dealer about antennas and the best place to mount points AVOID long cable runs to the antenna and power source KEEP these cables as far as possible from electrical pumps generators and other electronic instruments them 3
