IMPORTANT SAFETY PRECAUTIONS Before using the transceiver read all instructions carefully and completely AVOID placing the transceiver in direct sunlight This instruction manual contains important safety and operating instructions for the IC M56 KEEP the antenna cable and DC power cord as far away as possible from electrical pumps generators and other electrical instruments to prevent instru ment malfunctions NEVER connect the transceiver to more than a BE CAREFUL If the transceiver is not securely 16 V DC power source or an AC outlet This will ruin the transceiver mounted with bolts and nuts personal injury or transceiver damage could occur due to wave shock vibrations etc SAVE THESE INSTRUCTIONS NEVER allow children to touch the transceiver put the transceiver using in rain and snow NEVER in water AVOID AVOID using or placing the transceiver in areas with temperatures below 20 C 4 F or over 60 C 140 F BE CAREFUL The heatsink may become hot when the transceiver transmits continuously for a long time BE CAREFUL The transceiver is only weather resistant when four screws are securely tightened to the sides of the transceiver i
