5 FUNCTION OPERATION 5 1 MEMORY CHANNEL The transceiver has 20 memory channels The memory channels are especially useful to quickly call up channels you often use 4 Rotate the channel selector to select the desired channel you want to program When the dial mode has been selected in step 3 choose high or low transmit programming 1 READING A MEMORY CHANNEL 1 Push MR to select the memory mode 2 Rotate the channel selector to select the desired channel NOTE Only channels you have already program med can be selected If no memory channel is pro grammed the channel selector is deactivated 2 WRITING A MEMORY CHANNEL 1 Push and hold MR until the memory channel number blinks 2 Rotate the channel selector to select the desired memory channel number 3 Push DIAL or WX to select the desired mode When the dial mode has been selected choose U S A or international channels 10 5 Push MR to complete programming
