FUNCTION OPERATION 5 CHANNEL LOCKOUT 5 4 DIMMER CONTROL This function allows you to skip certain channels while scanning shortening interval scanning time The backlight intensity of the function display can be adjusted or turned OFF 1 To select the desired mode push DIAL WX or MR 1 TURNING OFF THE BACKLIGHT 2 Rotate the channel selector to select the channel to be locked out 1 While pushing HI LO push DIAL to turn OFF the display backlight 3 While pushing HI LO push DW SCN L appears on the function display 2 To turn the backlight ON again repeat step 1 4 To cancel the lockout function for that channel repeat step 3 2 ADJUSTING THE BACKLIGHT 1 While pushing HI LO push and hold DIAL 2 Hold DIAL release HI LO then rotate the channel selector The backlight intensity changes 13
