INSTALLATION 1 MOUNTING THE TRANSCEIVER The universal bracket supplied with your transceiver allows overhead or dashboard mounting Please read the following instructions carefully Install the bracket so the transceiver is adequately sup ported thus protecting it from wave shock and vibrations Try to avoid drilling new mounting holes in the bracket as the balance of the transceiver may be affected An optional MB 28 FLUSH MOUNT is available from Icom If you need special hardware for installation any good marine store may assist you 2
