PANEL DESCRIPTION SPEAKER TX INDICATOR TX1 Lights when transmitting FUNCTION DISPLAY Displays the current operating channel and additional information Refer to Section 3 3 FUNCTION DIS PLAY VOLUME CONTROL POWER SWITCH PWR VOL Turns power ON and OFF and adjusts the speaker volume MICROPHONE PTT Push To Talk SWITCH Push and hold to transmit and release to receive SQUELCH CONTROL SQUELCH Rotate clockwise to eliminate audio noise When a signal is received the squelch opens and audio is emitted from the speaker CHANNEL 16 SWITCH CH 16 Selects Channel 16 Used for emergency and distress calls and as call channel While pushing HI LO push this switch to select the U S A or International channels
