MAINTENANCE 6 6 2 FUSE REPLACEMENT 6 3 RESETTING THE CPU Two fuses are installed in the DC power cable If the fuses blow or the transceiver stops functioning track down the source of the problem if possible and replace the damaged fuse with a new rated fuse If the function display occasionally displays erroneous information when the power is turned ON or when operat ing reset the CPU Fuse rating 10 A BE CAREFUL After resetting the CPU all informa tion you have programmed into the memory channels will be erased 1 Turn power ON 2 Push and hold CH 16 and MR 3 Turn power OFF and then turn it ON again The function display illuminates all characters for a second 4 Release CH 16 and MR 15
