8 SPECIFICATIONS GENERAL Type of emission Antenna impedance Usable temperature range Frequency stability Power supply voltage Dimensions Weight 16K0G3E 50 ft 20 C 60 C 4 F 140 F 0 0005 13 8 V DC negative ground 140 W x 55 H x 155 D mm 5 5 W x 2 2 H x 6 1 D in Projections not included 1 1 kg 2 4 lb RECEIVER Frequency range Sensitivity Audio output power Intermediate frequency Current drain 156 163 MHz 0 3 MV for 12dBSINAD 4 W with a 4 ft load 1st 21 8 MHz 2nd 455 kHz 190 mA standby condition with no display backlight 1 0 A at max audio with brightest display TRANSMITTER Frequency range Output power Microphone impedance Current drain 18 156 157 5 MHz HIGH 25 W LOW 1W 600 ft 5 5 A at HIGH output power 1 4 A at LOW output power All stated specifications are subject to change without notice or obligation
