ED12-321A Capacity Tables
SUPER MULTI NX B-Series Heat Pump 115
3
3D042744#5
3D042744#6
3D042744#7
Combination
(Capacity)
Indoor
Air Temp.
°CDB
Outdoor Air Temp.:°CWB
-15 -10 -5 0 6 10 15
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
2.5+3.5+3.5+3.5 16 6.24 2.21 7.32 2.38 8.49 2.55 9.53 2.67 10.86 2.83 11.79 2.95 12.99 3.11
18 6.22 2.28 7.30 2.45 8.47 2.61 9.49 2.74 10.81 2.91 11.73 3.03 12.93 3.19
20 6.19 2.35 7.27 2.52 8.44 2.68 9.46 2.81
10.76 2.99 11.68 3.12 12.87 3.29
21 6.18 2.39 7.26 2.55 8.43 2.72 9.44 2.85 10.74 3.03 11.65 3.16 12.84 3.33
22 6.17 2.43 7.25 2.59 8.42 2.75 9.42 2.89 10.71 3.08 11.62 3.21 12.81 3.38
24 6.15 2.50 7.23 2.66 8.40 2.83 9.39 2.98 10.67 3.17 11.57 3.30 12.75 3.48
Symbols NOTE:
TC : Total capacity (kW) Capacities are based on the following conditions.
Corresponding refrigerant piping length : 7.5m
Level difference : 0m
PI : Power input (kW)
