ED12-321A Electric Characteristics
SUPER MULTI NX B-Series Heat Pump 133
3
11.Electric Characteristics
11.1 3MXD68BVMA
Cooling (50 / 60Hz 220V)
Heating (50 / 60Hz 220V)
3D039722#3
3D039722#4
Combination
Units Power Supply Comp. OFM IFM
Hz Volts Min. Max. MCA MFA RLA W FLA W FLA
2.5
50/60 220 198 242
5.4
20
3.4
68 0.41
40 0.23
3.5 7.1 5.6 40 0.23
5.0 8.8 8.1 40 0.23
6.0 13.6 12.2 45 0.25
2.5+2.5 8.9 7.5 80 0.45
2.5+3.5 12.5 10.2 80 0.45
2.5+5.0 10.9 9.2 80 0.45
2.5+6.0 11.6 9.8 85 0.48
3.5+3.5 12.5 10.8 80 0.45
3.5+5.0 11.8 10.0 80 0.45
3.5+6.0 12.7 10.6 85 0.48
5.0+5.0 10.9 9.3 80 0.45
5.0+6.0 10.9 9.7 85 0.48
2.5+2.5+2.5 10.8 8.0 120 0.68
2.5+2.5+3.5 11.1 8.6 120 0.68
2.5+2.5+5.0 10.8 8.4 120 0.68
2.5+2.5+6.0 12.0 9.1 125 0.70
2.5+3.5+3.5 12.3 9.4 120 0.68
2.5+3.5+5.0 12.0 9.1 120 0.68
3.5+3.5+3.5 12.8 9.3 120 0.68
Combination
Units Power Supply Comp. OFM IFM
Hz Volts Min. Max. MCA MFA RLA W FLA W FLA
2.5
50/60 220 198 242
8.0
20
5.7
68 0.41
40 0.23
3.5 9.8 7.3 40 0.23
5.0 12.9 9.2 40 0.23
6.0 15.2 12.0 45 0.25
2.5+2.5 13.9 10.4 80 0.45
2.5+3.5 15.3 11.6 80 0.45
2.5+5.0 14.0 12.6 80 0.45
2.5+6.0 14.3 12.7 85 0.48
3.5+3.5 14.9 12.6 80 0.45
3.5+5.0 14.5 12.8 80 0.45
3.5+6.0 14.4 12.4 85 0.48
5.0+5.0 13.2 10.9 80 0.45
5.0+6.0 13.2 10.6 85 0.48
2.5+2.5+2.5 14.6 12.1 120 0.68
2.5+2.5+3.5 14.6 11.4 120 0.68
2.5+2.5+5.0 13.1 10.6 120 0.68
2.5+2.5+6.0 12.9 10.5 125 0.70
2.5+3.5+3.5 14.6 11.0 120 0.68
2.5+3.5+5.0 13.1 10.4 120 0.68
3.5+3.5+3.5 14.1 10.5 120 0.68
SYMBOLS: NOTES:
MCA : MIN. CIRCUIT AMPS (A) 1. RLA is based on the following conditions.
Power Supply: 50 / 60Hz 220V
Cooling
Indoor temp.: 27°CDB/19°CWB
Outdoor temp.: 35°CDB.
Heating
Indoor temp.: 20°CDB
Outdoor temp.: 7°CDB/6°CWB.
2. Maximum allowable voltage variation between phases is 2%.
3. Select wire size based on the value of MCA.
4. Instead of fuse, use circuit breaker.
MFA : MAX. FUSE AMPS (A)
RLA : RATED LOAD AMPS (A)
OFM : OUTDOOR FAN MOTOR
IFM : INDOOR FAN MOTOR
FLA : FULL LOAD AMPS (A)
W : FAN MOTOR RATED OUTPUT (W)
