Electric Characteristics ED12-321A
134 SUPER MULTI NX B-Series Heat Pump
Cooling (50Hz 240V)
Heating (50Hz 240V)
3D039722#1
3D039722#2
Combination
Units Power Supply Comp. OFM IFM
Hz Volts Min. Max. MCA MFA RLA W FLA W FLA
2.5
50 240 216 264
5.0
20
3.1
68 0.41
40 0.23
3.5 6.5 5.1 40 0.23
5.0 8.1 7.4 40 0.23
6.0 12.5 11.2 45 0.25
2.5+2.5 8.2 6.8 80 0.45
2.5+3.5 11.4 9.3 80 0.45
2.5+5.0 10.0 8.4 80 0.45
2.5+6.0 10.6 9.0 85 0.48
3.5+3.5 11.4 9.9 80 0.45
3.5+5.0 10.8 9.2 80 0.45
3.5+6.0 11.6 9.7 85 0.48
5.0+5.0 10.0 8.5 80 0.45
5.0+6.0 10.0 8.8 85 0.48
2.5+2.5+2.5 9.9 7.3 120 0.68
2.5+2.5+3.5 10.1 7.8 120 0.68
2.5+2.5+5.0 9.9 7.6 120 0.68
2.5+2.5+6.0 11.0 8.3 125 0.70
2.5+3.5+3.5 11.3 8.6 120 0.68
2.5+3.5+5.0 11.0 8.3 120 0.68
3.5+3.5+3.5 11.7 8.5 120 0.68
Combination
Units Power Supply Comp. OFM IFM
Hz Volts Min. Max. MCA MFA RLA W FLA W FLA
2.5
50 240 216 264
7.4
20
5.2
68 0.41
40 0.23
3.5 9.0 6.7 40 0.23
5.0 11.9 8.4 40 0.23
6.0 14.0 11.0 45 0.25
2.5+2.5 12.8 9.5 80 0.45
2.5+3.5 14.0 10.6 80 0.45
2.5+5.0 12.9 11.6 80 0.45
2.5+6.0 13.1 11.6 85 0.48
3.5+3.5 13.6 11.6 80 0.45
3.5+5.0 13.3 11.7 80 0.45
3.5+6.0 13.2 11.4 85 0.48
5.0+5.0 12.1 10.0 80 0.45
5.0+6.0 12.1 9.7 85 0.48
2.5+2.5+2.5 13.3 11.1 120 0.68
2.5+2.5+3.5 13.3 10.4 120 0.68
2.5+2.5+5.0 12.0 9.7 120 0.68
2.5+2.5+6.0 11.9 9.6 125 0.70
2.5+3.5+3.5 13.3 10.1 120 0.68
2.5+3.5+5.0 12.0 9.5 120 0.68
3.5+3.5+3.5 12.9 9.6 120 0.68
SYMBOLS: NOTES:
MCA : MIN. CIRCUIT AMPS (A) 1. RLA is based on the following conditions.
Power Supply: 50Hz 240V
Cooling
Indoor temp.: 27°CDB/19°CWB
Outdoor temp.: 35°CDB.
Heating
Indoor temp.: 20°CDB
Outdoor temp.: 7°CDB/6°CWB.
2. Maximum allowable voltage variation between phases is 2%.
3. Select wire size based on the value of MCA.
4. Instead of fuse, use circuit breaker.
MFA : MAX. FUSE AMPS (A)
RLA : RATED LOAD AMPS (A)
OFM : OUTDOOR FAN MOTOR
IFM : INDOOR FAN MOTOR
FLA : FULL LOAD AMPS (A)
W : FAN MOTOR RATED OUTPUT (W)
